FMD400/ FMD600 medical waste shredder for waste treatment center

You are now at : Home >> Medical waste shredder >> FMD400/ FMD600 medical waste shredder for waste treatment center

Back to Medical waste shredder

We can supply large capacity shredding machine for medical waste treatment Center

FMD400/ FMD600 life waste/food waste/medical waste shredder

FMD400/FMD600 dual shaft shredder can be used for shredding various kinds of medical waste so that to reduce the volume by 85%.

Material include

Parameter for FMD400/FMD600

Model	FMD-400	FMD-600
Destroying method	Double shaft cutting
Product size	12007501350mm	13009001700mm
Hopper size	600*700mm	700*800mm
Waste outlet size	300mm*320mm	350mm*400mm
Size of waste after shredding	About 18mm
Crushing capacity	300-700kg/hour of medical waste	500kg~1200kg/hour of medical waste
Power supply	380/440V,50Hz/60Hz, three phase power supply
Internal protection	overload protection , leakage protection Thermal hypersensitivity protection
Interface voltage	Safety low voltage on the operation box
Output power	7500VA	11.5Kw
Material	Mild steel powder coated
Temperature	in operation:-5°C~+50°C stored:-20°C~+55°C
Relative humidity	60%~80%
	high-quality steel, 15mm thickness, dia 170mm
Motor	Quiet and low speed motor, with speed reducer.
Low noise	60 - 70 dB (A)
Rpm	25r/Minute
Weight	800kg	1000kg

Features and options

Safety protection:

Electric Leakage protection,

Over voltage and over current protection;

Interface safety voltage;

Emergency stop function;

With earthing conductor;

High torque,low speed technology

Efficiently process bulk fed,,though to shred

materials. Less downtime, noise and dust

emission than high speed shredders.

Professional Cutter design

We will help to design the proper number

and the length of hooks for cutters according

to various kinds of materials so that to

maximize throughput of the requirement

shred size

Bearing protection

Shredded contaminants are prevented

from reaching the bearings through the

use of false walls and seals.

Automatic shaft Reverse function

When over feeding, Automatic shaft

Reverse function will protecting against

damage .

Super low noise:

Its working noise is about 60-70dBa, so

it is more suitable for hospital use.
