FMD1000/ FMD1500/ FMD2000 DOUBLE SHAFT SHREDDER

    Back to Medical waste shredder

We have the professional engineers and will help to  design the proper cutting systems according to various  kinds of materials.

FMD1000/ FMD1500/ FMD2000

FMD dual shaft shredder can be used for shredding various kinds of materials so that to reduce  the volume by 85%.

Material include:

 Material include:
  •  Medical disposal waste
  •  Wood
  •  Paper&cardboard
  •  Clothing
  •  Life waste
  •  Plastics
  •  Rubber
  •  Texitiles&Fibers
  •  Food waste
  •  E-scrap




Parameter for FMD1000/ FMD1500/ FMD2000

Models

DOUBLE SHAFT SHREDDER

FMD1000/ FMD1500/ FMD2000


Destroying method

Electric Double shaft cutting

Product size

1000*1200*2100mm(FMD1000)

1200*1450*2200mm (FMD1500)

2000*1300*2300mm (FMD2000)

Number of motor

2

Crushing capacity

1000~1500kg/h(FMD1000)

1500~2000kg/h(FMD1500)

2200~3000kg/h(FMD2000)

Horsepower

FMD1000:15KW

FMD1500:22KW

FMD2000:30KW

Power supply

three phase power supply

Internal protection

overload protection , leakage protection

Thermal hypersensitivity protection,

Interface voltage

Safety low voltage on the operation panel.

Motor

Quiet and low speed motor.

Low noise

60 - 70 dB (A)

Rpm

30-35

Weight

 G.W:1500KG(FMD1000) / G.W:2000KG (FMD1500)/G.W:3000KG(FMD2000)

Features and options:

Safety protection:

Electric Leakage protection,

Over voltage and over current protection;

Interface safety voltage;

Emergency stop function;

With earthing conductor;

High torque,low speed technology

Efficiently process bulk fed,,though to shred

materials. Less downtime, noise and dust

emission than high speed shredders.

Professional Cutter design

We will help to design the proper number

 and the length of hooks for cutters according

 to various kinds of materials so that to

maximize throughput of the requirement

 shred size

Bearing protection

Shredded contaminants are prevented

from reaching the bearings through the

 use of false walls and seals.

Automatic shaft Reverse function

When over feeding, Automatic shaft

Reverse function will protecting against

damage .

Super low noise:

Its working noise is about 60-70dBa, so

 it is more suitable for hospital use.
